Create a Kubernetes CNI Plugin from Scratch

Posted Updated
Kubernetes CNI from scratch
Kubernetes CNI from scratch
By Simone Rodigari 25 min read

Introduction

A Kubernetes Pod starts inside a new network namespace with no useful network interface. The container runtime then executes a Container Network Interface (CNI) plugin and asks it to connect that namespace to the cluster.

In this post, we will write that plugin in Bash or Go. We will start with one Pod and one fixed IP, then add IP address management, same-node Pod-to-Pod communication, and finally cross-node routing.

Every command is complete and can be pasted without replacing placeholders. The lab works on macOS or Linux with the host tools listed below. The Go implementation also requires Go 1.24 or newer.

This is an educational bridge CNI. It implements the core ADD, DEL, CHECK, STATUS, and VERSION behavior, but not NetworkPolicy, encryption, observability, IPv6, or route distribution. Those are some of the reasons production CNIs are larger systems.

What We Will Build

The plugin will create a Linux bridge named cni0. For every Pod, it will create a veth pair, move one end into the Pod network namespace as eth0, and attach the host end to the bridge.

flowchart LR
    CR[containerd] -->|CNI ADD| CNI[cni-plugin]
    CNI --> IPAM[IPAM plugin]
    CNI --> BR[cni0 bridge]

    subgraph PodNS [Pod network namespace]
        ETH[eth0<br>Pod IP]
    end

    BR <-->|host veth| ETH

The implementation stays unchanged throughout the tutorial. We add capabilities by changing only:

  • the CNI configuration installed on each node;
  • the routes and kernel settings configured on the hosts.

The CNI Contract

CNI is not a daemon or a Kubernetes API. It is an executable protocol between a runtime and a plugin. The runtime:

  1. creates the Pod network namespace;
  2. sets environment variables such as CNI_COMMAND, CNI_CONTAINERID, CNI_NETNS, and CNI_IFNAME;
  3. sends JSON configuration to the plugin on standard input;
  4. expects JSON on standard output for a successful ADD.

The commands relevant to this plugin are:

CommandResponsibility
ADDCreate the interface and return its addresses and routes
DELRemove the interface and release its addresses
CHECKVerify that the result of ADD still exists
STATUSReport whether the plugin and delegated IPAM are ready
VERSIONReport supported CNI specification versions

The CNI specification also requires repeated DEL calls to succeed when resources are already gone. This matters because a runtime can call DEL after the network namespace has disappeared.

Why Delegate IPAM?

Creating interfaces and allocating addresses are different jobs. The CNI specification defines IPAM delegation so a main plugin can call another plugin for an address, gateway, and routes. Our plugin will work with both the standard static and host-local IPAM plugins.

%%{init: {'sequence': {'mirrorActors': false}}}%%
sequenceDiagram
    participant R as containerd
    participant C as cni-plugin
    participant I as IPAM
    participant N as Linux networking

    R->>C: ADD + netns + JSON
    C->>N: Create cni0 and veth pair
    C->>I: Delegated ADD
    I-->>C: IP, gateway, routes
    C->>N: Configure eth0 and cni0
    C-->>R: CNI result

Prerequisites

Choose an implementation. Changing the language here also changes the implementation shown in the next section.

The host running the Bash implementation requires:

  • Docker;
  • kind v0.33.0 or newer;
  • kubectl;
  • curl and tar;
  • either shasum or sha256sum.

The plugin itself runs inside the kind nodes. It requires Bash, jq, ip, sysctl, sha256sum, grep, basename, and readlink. The pinned node image used below supplies all of them; the delegated static and host-local IPAM executables are installed in section 2.

Confirm that the host commands exist:

1
2
3
4
5
6

docker version --format 'Docker {{.Server.Version}}'
kind version
kubectl version --client
command -v curl
command -v tar
command -v shasum || command -v sha256sum

The host running the Go implementation requires:

  • Docker;
  • kind v0.33.0 or newer;
  • kubectl;
  • curl, tar, and file;
  • either shasum or sha256sum;
  • Go 1.24 or newer.

Confirm that the host commands exist:

1
2
3
4
5
6
7
8

docker version --format 'Docker {{.Server.Version}}'
kind version
kubectl version --client
go version
command -v curl
command -v tar
command -v file
command -v shasum || command -v sha256sum

1. Create the Plugin

Create a clean working directory:

1
2

mkdir -p "$HOME/cni-plugin-lab"
cd "$HOME/cni-plugin-lab"

Choose either implementation below. Both produce the same executable name and consume the same CNI configuration used throughout the rest of the tutorial.

Create the Go module. The module versions are pinned so that the commands remain reproducible:

1
2
3
4
5
6
7
8
9
10
11

cat > go.mod <<'EOF'
module example.com/cni-plugin

go 1.24.0

require (
	github.com/containernetworking/cni v1.3.1
	github.com/containernetworking/plugins v1.9.1
	github.com/vishvananda/netlink v1.3.1-0.20250219173312-258359450bc3
)
EOF

Create the plugin:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247

cat > main.go <<'EOF'
package main

import (
	"encoding/json"
	"errors"
	"fmt"
	"net"
	"runtime"
	"syscall"

	"github.com/containernetworking/cni/pkg/skel"
	"github.com/containernetworking/cni/pkg/types"
	current "github.com/containernetworking/cni/pkg/types/100"
	"github.com/containernetworking/cni/pkg/version"
	"github.com/containernetworking/plugins/pkg/ip"
	"github.com/containernetworking/plugins/pkg/ipam"
	"github.com/containernetworking/plugins/pkg/ns"
	"github.com/containernetworking/plugins/pkg/utils/buildversion"
	"github.com/vishvananda/netlink"
)

type NetConf struct {
	types.NetConf
	Bridge string `json:"bridge"`
	MTU    int    `json:"mtu"`
}

func init() {
	runtime.LockOSThread()
}

func loadConf(data []byte) (*NetConf, error) {
	conf := &NetConf{Bridge: "cni0", MTU: 1500}
	if err := json.Unmarshal(data, conf); err != nil {
		return nil, fmt.Errorf("decode network configuration: %w", err)
	}
	if conf.IPAM.Type == "" {
		return nil, errors.New("ipam.type is required")
	}
	return conf, nil
}

func ensureBridge(name string, mtu int) (*netlink.Bridge, error) {
	link, err := netlink.LinkByName(name)
	if err == nil {
		bridge, ok := link.(*netlink.Bridge)
		if !ok {
			return nil, fmt.Errorf("%q exists but is not a bridge", name)
		}
		return bridge, netlink.LinkSetUp(bridge)
	}

	attrs := netlink.NewLinkAttrs()
	attrs.Name = name
	attrs.MTU = mtu
	bridge := &netlink.Bridge{LinkAttrs: attrs}
	if err := netlink.LinkAdd(bridge); err != nil && err != syscall.EEXIST {
		return nil, fmt.Errorf("create bridge %q: %w", name, err)
	}
	link, err = netlink.LinkByName(name)
	if err != nil {
		return nil, fmt.Errorf("find bridge %q: %w", name, err)
	}
	bridge, ok := link.(*netlink.Bridge)
	if !ok {
		return nil, fmt.Errorf("%q is not a bridge", name)
	}
	return bridge, netlink.LinkSetUp(bridge)
}

func ensureGateway(bridge netlink.Link, gateway net.IP, mask net.IPMask) error {
	address := &netlink.Addr{IPNet: &net.IPNet{IP: gateway, Mask: mask}}
	if err := netlink.AddrAdd(bridge, address); err != nil && err != syscall.EEXIST {
		return fmt.Errorf("add gateway %s to %s: %w", gateway, bridge.Attrs().Name, err)
	}
	return ip.EnableIP4Forward()
}

func cmdAdd(args *skel.CmdArgs) error {
	conf, err := loadConf(args.StdinData)
	if err != nil {
		return err
	}
	bridge, err := ensureBridge(conf.Bridge, conf.MTU)
	if err != nil {
		return err
	}

	netns, err := ns.GetNS(args.Netns)
	if err != nil {
		return fmt.Errorf("open network namespace %q: %w", args.Netns, err)
	}
	defer netns.Close()

	hostNS, err := ns.GetCurrentNS()
	if err != nil {
		return fmt.Errorf("open host network namespace: %w", err)
	}
	defer hostNS.Close()

	var hostInterface, containerInterface *current.Interface
	err = netns.Do(func(_ ns.NetNS) error {
		hostVeth, containerVeth, err := ip.SetupVeth(args.IfName, conf.MTU, "", hostNS)
		if err != nil {
			return err
		}
		hostInterface = &current.Interface{Name: hostVeth.Name, Mac: hostVeth.HardwareAddr.String()}
		containerInterface = &current.Interface{
			Name:    containerVeth.Name,
			Mac:     containerVeth.HardwareAddr.String(),
			Sandbox: args.Netns,
		}
		return nil
	})
	if err != nil {
		return fmt.Errorf("create veth pair: %w", err)
	}

	success := false
	defer func() {
		if !success {
			_ = netns.Do(func(_ ns.NetNS) error { return ip.DelLinkByName(args.IfName) })
		}
	}()

	hostVeth, err := netlink.LinkByName(hostInterface.Name)
	if err != nil {
		return fmt.Errorf("find host veth %q: %w", hostInterface.Name, err)
	}
	if err := netlink.LinkSetMaster(hostVeth, bridge); err != nil {
		return fmt.Errorf("attach %s to %s: %w", hostInterface.Name, conf.Bridge, err)
	}

	ipamResult, err := ipam.ExecAdd(conf.IPAM.Type, args.StdinData)
	if err != nil {
		return fmt.Errorf("IPAM ADD: %w", err)
	}
	defer func() {
		if !success {
			_ = ipam.ExecDel(conf.IPAM.Type, args.StdinData)
		}
	}()

	result, err := current.NewResultFromResult(ipamResult)
	if err != nil {
		return fmt.Errorf("convert IPAM result: %w", err)
	}
	if len(result.IPs) == 0 {
		return errors.New("IPAM returned no addresses")
	}

	result.Interfaces = []*current.Interface{
		{Name: bridge.Attrs().Name, Mac: bridge.Attrs().HardwareAddr.String()},
		hostInterface,
		containerInterface,
	}
	for _, address := range result.IPs {
		if address.Address.IP.To4() == nil {
			return errors.New("this tutorial plugin supports IPv4 only")
		}
		address.Interface = current.Int(2)
		if address.Gateway != nil {
			if err := ensureGateway(bridge, address.Gateway, address.Address.Mask); err != nil {
				return err
			}
		}
	}

	if err := netns.Do(func(_ ns.NetNS) error {
		return ipam.ConfigureIface(args.IfName, result)
	}); err != nil {
		return fmt.Errorf("configure %s: %w", args.IfName, err)
	}

	success = true
	return types.PrintResult(result, conf.CNIVersion)
}

func cmdDel(args *skel.CmdArgs) error {
	conf, err := loadConf(args.StdinData)
	if err != nil {
		return err
	}

	if args.Netns != "" {
		err = ns.WithNetNSPath(args.Netns, func(_ ns.NetNS) error {
			err := ip.DelLinkByName(args.IfName)
			if err == ip.ErrLinkNotFound {
				return nil
			}
			return err
		})
		var missing ns.NSPathNotExistErr
		if err != nil && !errors.As(err, &missing) {
			return err
		}
	}
	return ipam.ExecDel(conf.IPAM.Type, args.StdinData)
}

func cmdCheck(args *skel.CmdArgs) error {
	conf, err := loadConf(args.StdinData)
	if err != nil {
		return err
	}
	if err := ipam.ExecCheck(conf.IPAM.Type, args.StdinData); err != nil {
		return err
	}
	if conf.RawPrevResult == nil {
		return errors.New("CHECK requires prevResult")
	}
	if err := version.ParsePrevResult(&conf.NetConf); err != nil {
		return err
	}
	result, err := current.NewResultFromResult(conf.PrevResult)
	if err != nil {
		return err
	}
	if _, err := netlink.LinkByName(conf.Bridge); err != nil {
		return fmt.Errorf("bridge %s is missing: %w", conf.Bridge, err)
	}
	return ns.WithNetNSPath(args.Netns, func(_ ns.NetNS) error {
		if err := ip.ValidateExpectedInterfaceIPs(args.IfName, result.IPs); err != nil {
			return err
		}
		return ip.ValidateExpectedRoute(result.Routes)
	})
}

func cmdStatus(args *skel.CmdArgs) error {
	conf, err := loadConf(args.StdinData)
	if err != nil {
		return err
	}
	return ipam.ExecStatus(conf.IPAM.Type, args.StdinData)
}

func main() {
	skel.PluginMainFuncs(skel.CNIFuncs{
		Add:    cmdAdd,
		Del:    cmdDel,
		Check:  cmdCheck,
		Status: cmdStatus,
	}, version.All, buildversion.BuildString("cni-plugin"))
}
EOF

There are four important details in the code:

  1. runtime.LockOSThread() prevents a goroutine from changing OS threads while entering a network namespace.
  2. ip.SetupVeth() creates the virtual cable and moves its host end back to the node namespace.
  3. ipam.ExecAdd() delegates allocation; ipam.ConfigureIface() applies the returned address and routes.
  4. Deferred cleanup releases both the veth and the IP allocation when ADD fails halfway through.

Download the dependencies and compile a Linux binary for the same architecture as the Docker nodes:

1
2
3
4
5
6
7
8

go mod tidy
case "$(docker info --format '{{.Architecture}}')" in
  x86_64) NODE_GOARCH=amd64 ;;
  aarch64) NODE_GOARCH=arm64 ;;
  *) echo "Unsupported Docker architecture" >&2; exit 1 ;;
esac
CGO_ENABLED=0 GOOS=linux GOARCH="$NODE_GOARCH" go build -trimpath -o cni-plugin .
file cni-plugin

The Bash implementation uses ip, jq, sha256sum, and the delegated IPAM executable. These tools are already present in the pinned kind node image after the IPAM installation step below.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162

cat > cni-plugin <<'EOF'
#!/usr/bin/env bash
set -uo pipefail

CONFIG=$(cat)
CNI_VERSION=$(jq -r '.cniVersion // "1.1.0"' <<<"$CONFIG")

fail() {
	jq -n --arg version "$CNI_VERSION" --arg message "$1" \
		'{cniVersion:$version,code:100,msg:"cni-plugin failed",details:$message}'
	exit 1
}

find_plugin() {
	local name=$1 directory
	IFS=: read -ra directories <<<"${CNI_PATH:-/opt/cni/bin}"
	for directory in "${directories[@]}"; do
		if [[ -x "$directory/$name" ]]; then
			printf '%s\n' "$directory/$name"
			return 0
		fi
	done
	return 1
}

delegate() {
	local command=$1 ipam_type ipam_plugin
	ipam_type=$(jq -er '.ipam.type' <<<"$CONFIG") || fail "ipam.type is required"
	ipam_plugin=$(find_plugin "$ipam_type") || fail "IPAM plugin $ipam_type not found"
	CNI_COMMAND=$command "$ipam_plugin" <<<"$CONFIG"
}

host_veth_name() {
	local digest
	digest=$(printf '%s' "$CNI_CONTAINERID-$CNI_IFNAME" | sha256sum)
	printf 'veth%s\n' "${digest:0:10}"
}

netns_name() {
	[[ ${CNI_NETNS:-} == /var/run/netns/* ]] || \
		fail "this Bash implementation requires CNI_NETNS under /var/run/netns"
	basename "$CNI_NETNS"
}

cmd_add() {
	[[ -n ${CNI_CONTAINERID:-} && -n ${CNI_NETNS:-} && -n ${CNI_IFNAME:-} ]] || \
		fail "ADD requires CNI_CONTAINERID, CNI_NETNS, and CNI_IFNAME"

	local bridge mtu host_veth peer netns ipam_result address gateway prefix
	bridge=$(jq -r '.bridge // "cni0"' <<<"$CONFIG")
	mtu=$(jq -r '.mtu // 1500' <<<"$CONFIG")
	host_veth=$(host_veth_name)
	peer="peer${host_veth:4}"
	netns=$(netns_name)

	if ip link show "$bridge" &>/dev/null; then
		[[ -d "/sys/class/net/$bridge/bridge" ]] || fail "$bridge exists but is not a bridge"
	else
		ip link add "$bridge" type bridge || fail "could not create bridge $bridge"
	fi
	ip link set "$bridge" mtu "$mtu" up || fail "could not enable bridge $bridge"

	ip link add "$host_veth" mtu "$mtu" type veth peer name "$peer" || \
		fail "could not create veth pair"
	trap 'ip link delete "$host_veth" 2>/dev/null || true' EXIT
	ip link set "$peer" netns "$netns" || fail "could not move veth into $CNI_NETNS"
	ip -n "$netns" link set "$peer" name "$CNI_IFNAME" || fail "could not rename Pod veth"
	ip -n "$netns" link set "$CNI_IFNAME" mtu "$mtu" || fail "could not set Pod MTU"
	ip link set "$host_veth" master "$bridge" up || fail "could not attach veth to $bridge"
	ip -n "$netns" link set lo up
	ip -n "$netns" link set "$CNI_IFNAME" up

	ipam_result=$(delegate ADD) || fail "IPAM ADD failed"
	trap 'delegate DEL >/dev/null 2>&1 || true; ip link delete "$host_veth" 2>/dev/null || true' EXIT
	address=$(jq -er '.ips[0].address' <<<"$ipam_result") || fail "IPAM returned no address"
	gateway=$(jq -er '.ips[0].gateway' <<<"$ipam_result") || fail "IPAM returned no gateway"
	[[ $address == *.* ]] || fail "this tutorial plugin supports IPv4 only"
	prefix=${address#*/}

	ip -n "$netns" address add "$address" dev "$CNI_IFNAME" || fail "could not add Pod address"
	while IFS=$'\t' read -r destination route_gateway; do
		if [[ -n $route_gateway ]]; then
			ip -n "$netns" route replace "$destination" via "$route_gateway" dev "$CNI_IFNAME"
		else
			ip -n "$netns" route replace "$destination" via "$gateway" dev "$CNI_IFNAME"
		fi
	done < <(jq -r '.routes[]? | [.dst, (.gw // "")] | @tsv' <<<"$ipam_result")

	ip address replace "$gateway/$prefix" dev "$bridge" || fail "could not configure bridge gateway"
	sysctl -qw net.ipv4.ip_forward=1 || fail "could not enable IPv4 forwarding"

	local bridge_mac host_mac pod_mac
	bridge_mac=$(cat "/sys/class/net/$bridge/address")
	host_mac=$(cat "/sys/class/net/$host_veth/address")
	pod_mac=$(ip -n "$netns" -j link show "$CNI_IFNAME" | jq -r '.[0].address')

	jq -n \
		--arg version "$CNI_VERSION" --arg bridge "$bridge" --arg bridge_mac "$bridge_mac" \
		--arg host "$host_veth" --arg host_mac "$host_mac" --arg ifname "$CNI_IFNAME" \
		--arg pod_mac "$pod_mac" --arg sandbox "$CNI_NETNS" --argjson ipam "$ipam_result" \
		'{cniVersion:$version,
			interfaces:[
				{name:$bridge,mac:$bridge_mac},
				{name:$host,mac:$host_mac},
				{name:$ifname,mac:$pod_mac,sandbox:$sandbox}
			],
			ips:($ipam.ips | map(. + {interface:2})),
			routes:($ipam.routes // []),
			dns:($ipam.dns // {})}'
	trap - EXIT
}

cmd_del() {
	local host_veth
	host_veth=$(host_veth_name)
	ip link delete "$host_veth" 2>/dev/null || true
	delegate DEL >/dev/null || fail "IPAM DEL failed"
}

cmd_check() {
	local bridge host_veth netns address destination gateway
	bridge=$(jq -r '.bridge // "cni0"' <<<"$CONFIG")
	host_veth=$(host_veth_name)
	netns=$(netns_name)
	address=$(jq -er '.prevResult.ips[0].address' <<<"$CONFIG") || fail "CHECK requires prevResult"

	delegate CHECK >/dev/null || fail "IPAM CHECK failed"
	[[ -d "/sys/class/net/$bridge/bridge" ]] || fail "bridge $bridge is missing"
	ip link show "$host_veth" &>/dev/null || fail "host veth $host_veth is missing"
	[[ $(basename "$(readlink "/sys/class/net/$host_veth/master")") == "$bridge" ]] || \
		fail "$host_veth is not attached to $bridge"
	ip -n "$netns" link show "$CNI_IFNAME" &>/dev/null || fail "Pod interface is missing"
	ip -n "$netns" -4 address show dev "$CNI_IFNAME" | grep -Fq "${address%/*}/" || \
		fail "Pod address $address is missing"
	while IFS=$'\t' read -r destination gateway; do
		if [[ -n $gateway ]]; then
			ip -n "$netns" route show "$destination" | grep -Fq "via $gateway" || \
				fail "route $destination via $gateway is missing"
		else
			ip -n "$netns" route show "$destination" | grep -q . || fail "route $destination is missing"
		fi
	done < <(jq -r '.prevResult.routes[]? | [.dst, (.gw // "")] | @tsv' <<<"$CONFIG")
}

cmd_status() {
	delegate STATUS >/dev/null || fail "IPAM STATUS failed"
}

case ${CNI_COMMAND:-} in
	ADD) cmd_add ;;
	DEL) cmd_del ;;
	CHECK) cmd_check ;;
	STATUS) cmd_status ;;
	VERSION)
		jq -n --arg version "$CNI_VERSION" \
			'{cniVersion:$version,supportedVersions:["0.4.0","1.0.0","1.1.0"]}'
		;;
	*) fail "unsupported CNI_COMMAND: ${CNI_COMMAND:-<empty>}" ;;
esac
EOF

chmod 0755 cni-plugin

The host-side veth name is derived from the container ID and interface name. This lets DEL find and remove it even when the Pod network namespace has already disappeared. Failed ADD calls use shell traps to roll back both the veth and delegated IPAM allocation.

2. Create a Cluster Without a CNI

We disable kind’s default CNI because containerd must execute our binary. The node image is pinned to the digest published with kind v0.33.0.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

cat > kind.yaml <<'EOF'
kind: Cluster
apiVersion: kind.x-k8s.io/v1alpha4
name: cni-lab
networking:
  disableDefaultCNI: true
  podSubnet: 10.244.0.0/16
  serviceSubnet: 10.96.0.0/16
nodes:
- role: control-plane
  image: kindest/node:v1.37.0@sha256:a1ed56cfb0e7b93589bdf97c8cd566405a265939e3620fc4f5de89adff580ae5
- role: worker
  image: kindest/node:v1.37.0@sha256:a1ed56cfb0e7b93589bdf97c8cd566405a265939e3620fc4f5de89adff580ae5
EOF

kind delete cluster --name cni-lab
kind create cluster --config kind.yaml

The nodes remain NotReady. That is expected: there is no CNI configuration yet.

1
2
3
4

kubectl get nodes
kubectl get nodes \
  -o custom-columns=NAME:.metadata.name,PODCIDR:.spec.podCIDR
kubectl taint node cni-lab-worker cni-plugin-stage=static:NoSchedule

The extra taint reserves the worker for the fixed-address experiment. Without it, controllers such as CoreDNS or local-path-provisioner could create Pod sandboxes as soon as the worker becomes Ready. Every sandbox created with the static configuration would receive 10.244.1.2, and changing the CNI file later would not update those running Pods.

Install our binary on both nodes:

1
2
3
4

for node in cni-lab-control-plane cni-lab-worker; do
  docker cp cni-plugin "$node:/opt/cni/bin/cni-plugin"
  docker exec "$node" chmod 0755 /opt/cni/bin/cni-plugin
done

Install the standard CNI IPAM executables. The archive and checksum are selected automatically for either an AMD64 or ARM64 Docker engine:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

case "$(docker info --format '{{.Architecture}}')" in
  x86_64)
    CNI_ARCH=amd64
    CNI_SHA256=b98f74a0f8522f0a83867178729c1aa70f2158f90c45a2ca8fa791db1c76b303
    ;;
  aarch64)
    CNI_ARCH=arm64
    CNI_SHA256=56171987d3947707c3563db2f4001bccaf50fd63468611b9f3cbecb1375ee7ec
    ;;
  *) echo "Unsupported Docker architecture" >&2; exit 1 ;;
esac
curl -fL -o cni-plugins.tgz "https://github.com/containernetworking/plugins/releases/download/v1.9.1/cni-plugins-linux-${CNI_ARCH}-v1.9.1.tgz"
if command -v shasum >/dev/null; then
  echo "${CNI_SHA256}  cni-plugins.tgz" | shasum -a 256 --check
else
  echo "${CNI_SHA256}  cni-plugins.tgz" | sha256sum --check
fi
mkdir -p cni-plugins
tar -xzf cni-plugins.tgz -C cni-plugins
for node in cni-lab-control-plane cni-lab-worker; do
  docker cp cni-plugins/static "$node:/opt/cni/bin/static"
  docker cp cni-plugins/host-local "$node:/opt/cni/bin/host-local"
done

3. Start Simple: One Fixed Address

For the first call, use the standard static IPAM plugin on the worker. We intentionally leave the control-plane node without a CNI configuration during this stage: a fixed address is suitable for demonstrating one attachment, not for the multiple system Pods that the control plane will start.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

cat > 10-cni-plugin-worker.conf <<'EOF'
{
  "cniVersion": "1.1.0",
  "name": "cni-plugin",
  "type": "cni-plugin",
  "bridge": "cni0",
  "mtu": 1500,
  "ipam": {
    "type": "static",
    "addresses": [
      {"address": "10.244.1.2/24", "gateway": "10.244.1.1"}
    ],
    "routes": [
      {"dst": "0.0.0.0/0"}
    ]
  }
}
EOF

docker cp 10-cni-plugin-worker.conf cni-lab-worker:/etc/cni/net.d/10-cni-plugin.conf
kubectl wait --for=condition=Ready node/cni-lab-worker --timeout=120s

Create one Pod on the worker:

1
2
3
4
5
6
7

kubectl run fixed-ip \
  --image=registry.k8s.io/e2e-test-images/agnhost:2.53 \
	--overrides='{"spec":{"nodeSelector":{"kubernetes.io/hostname":"cni-lab-worker"},"tolerations":[{"key":"cni-plugin-stage","operator":"Equal","value":"static","effect":"NoSchedule"}],"containers":[{"name":"fixed-ip","image":"registry.k8s.io/e2e-test-images/agnhost:2.53","args":["pause"]}]}}'
kubectl wait --for=condition=Ready pod/fixed-ip --timeout=120s
kubectl get pod fixed-ip -o wide
kubectl exec fixed-ip -- ip -4 address show dev eth0
kubectl exec fixed-ip -- ip route

The Pod has 10.244.1.2/24, and its default route points to 10.244.1.1. On the node, the bridge owns that gateway and the host-side veth is attached to it:

1
2

docker exec cni-lab-worker ip -4 address show dev cni0
docker exec cni-lab-worker bridge link

This proves the complete CNI call works, but the configuration cannot create a second Pod on the same node: both would receive the same address. Delete it before changing IPAM:

1

kubectl delete pod fixed-ip --wait=true

4. Add IP Address Management

The standard host-local IPAM plugin stores allocations under /var/lib/cni/networks/<network-name> and prevents duplicate addresses on one host. It does not coordinate between hosts, so each node must receive a disjoint range.

Only the ipam configuration changes:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46

cat > 10-cni-plugin-control-plane.conf <<'EOF'
{
  "cniVersion": "1.1.0",
  "name": "cni-plugin",
  "type": "cni-plugin",
  "bridge": "cni0",
  "mtu": 1500,
  "ipam": {
    "type": "host-local",
    "ranges": [[
      {"subnet": "10.244.0.0/24", "gateway": "10.244.0.1"}
    ]],
    "routes": [
      {"dst": "0.0.0.0/0"}
    ]
  }
}
EOF

cat > 10-cni-plugin-worker.conf <<'EOF'
{
  "cniVersion": "1.1.0",
  "name": "cni-plugin",
  "type": "cni-plugin",
  "bridge": "cni0",
  "mtu": 1500,
  "ipam": {
    "type": "host-local",
    "ranges": [[
      {"subnet": "10.244.1.0/24", "gateway": "10.244.1.1"}
    ]],
    "routes": [
      {"dst": "0.0.0.0/0"}
    ]
  }
}
EOF

docker cp 10-cni-plugin-control-plane.conf cni-lab-control-plane:/etc/cni/net.d/10-cni-plugin.conf
docker cp 10-cni-plugin-worker.conf cni-lab-worker:/etc/cni/net.d/10-cni-plugin.conf
kubectl wait --for=condition=Ready nodes --all --timeout=120s
kubectl rollout restart deployment/coredns -n kube-system
kubectl rollout restart deployment/local-path-provisioner -n local-path-storage
kubectl taint node cni-lab-worker cni-plugin-stage:NoSchedule-
kubectl rollout status deployment/coredns -n kube-system --timeout=120s
kubectl rollout status deployment/local-path-provisioner -n local-path-storage --timeout=120s

Restarting these deployments is deliberate. CNI configuration is applied only during sandbox creation, so deleting or restarting a Pod is the supported way to attach it with the new host-local configuration. The taint prevented the add-ons from using the static address; the restarts also make this transition safe if a system Pod was created during an earlier or partially repeated run of the lab.

Create two Pods on the worker:

1
2
3
4
5
6
7
8

for pod in pod-a pod-b; do
  kubectl run "$pod" \
    --image=registry.k8s.io/e2e-test-images/agnhost:2.53 \
    --overrides="{\"spec\":{\"nodeSelector\":{\"kubernetes.io/hostname\":\"cni-lab-worker\"},\"containers\":[{\"name\":\"$pod\",\"image\":\"registry.k8s.io/e2e-test-images/agnhost:2.53\",\"args\":[\"pause\"]}]}}"
done
kubectl wait --for=condition=Ready pod/pod-a pod/pod-b --timeout=120s
kubectl get pods -o wide
docker exec cni-lab-worker find /var/lib/cni/networks/cni-plugin -maxdepth 1 -type f -print

Each Pod now receives a unique address from 10.244.1.0/24.

5. Same-Node Pod-to-Pod Communication

No new code or configuration is required. Both host-side veth interfaces are bridge ports, so cni0 forwards Ethernet frames between them.

flowchart LR
    subgraph Worker [Worker node]
        subgraph A [pod-a netns]
            AE[eth0<br>10.244.1.2]
        end
        subgraph B [pod-b netns]
            BE[eth0<br>10.244.1.3]
        end
        AE <-->|veth| BR[cni0<br>Linux bridge]
        BR <-->|veth| BE
    end

Test the path without manually copying an IP:

1
2
3

POD_B_IP=$(kubectl get pod pod-b -o jsonpath='{.status.podIP}')
kubectl exec pod-a -- ping -c 3 "$POD_B_IP"
docker exec cni-lab-worker bridge fdb show br cni0

The bridge forwards same-subnet traffic at Layer 2. The default gateway is not involved in this packet path.

6. Cross-Node Pod-to-Pod Communication

Now create a Pod on the control-plane node:

1
2
3
4
5

kubectl run pod-c \
  --image=registry.k8s.io/e2e-test-images/agnhost:2.53 \
  --overrides='{"spec":{"nodeSelector":{"kubernetes.io/hostname":"cni-lab-control-plane"},"tolerations":[{"operator":"Exists"}],"containers":[{"name":"pod-c","image":"registry.k8s.io/e2e-test-images/agnhost:2.53","args":["pause"]}]}}'
kubectl wait --for=condition=Ready pod/pod-c --timeout=120s
kubectl get pods -o wide

The first cross-node ping fails because neither node has a route to the other node’s Pod subnet:

1
2

POD_C_IP=$(kubectl get pod pod-c -o jsonpath='{.status.podIP}')
kubectl exec pod-a -- ping -c 2 -W 1 "$POD_C_IP" || true

Install Host Routes

The kind nodes already share a Docker network. We can use each node’s Docker-network IP as the next hop for the remote Pod subnet:

1
2
3
4
5
6
7

CONTROL_PLANE_IP=$(docker inspect -f '{{range .NetworkSettings.Networks}}{{.IPAddress}}{{end}}' cni-lab-control-plane)
WORKER_IP=$(docker inspect -f '{{range .NetworkSettings.Networks}}{{.IPAddress}}{{end}}' cni-lab-worker)

docker exec cni-lab-control-plane ip route replace 10.244.1.0/24 via "$WORKER_IP"
docker exec cni-lab-worker ip route replace 10.244.0.0/24 via "$CONTROL_PLANE_IP"
docker exec cni-lab-control-plane sysctl -w net.ipv4.ip_forward=1
docker exec cni-lab-worker sysctl -w net.ipv4.ip_forward=1

The packet path is now:

flowchart LR
    PA[pod-a<br>10.244.1.x] --> WB[cni0<br>10.244.1.1]
    subgraph W [Worker node]
        WB --> WR[Route to<br>10.244.0.0/24]
    end
    WR -->|kind Docker network| CR[Route to<br>10.244.0.0/24]
    subgraph C [Control-plane node]
        CR --> CB[cni0<br>10.244.0.1]
    end
    CB --> PC[pod-c<br>10.244.0.x]

Verify both directions:

1
2
3
4
5
6

POD_A_IP=$(kubectl get pod pod-a -o jsonpath='{.status.podIP}')
POD_C_IP=$(kubectl get pod pod-c -o jsonpath='{.status.podIP}')
kubectl exec pod-a -- ping -c 3 "$POD_C_IP"
kubectl exec pod-c -- ping -c 3 "$POD_A_IP"
docker exec cni-lab-worker ip route get "$POD_C_IP"
docker exec cni-lab-control-plane ip route get "$POD_A_IP"

The original source and destination Pod IPs remain unchanged. That satisfies the Kubernetes network model without NAT for Pod-to-Pod traffic.

These routes are intentionally configured by hand to expose the mechanism. A production CNI distributes equivalent reachability through node agents, the Kubernetes API, BGP, cloud routes, or an overlay such as VXLAN or Geneve.

What Changed at Each Stage?

StagePlugin binaryCNI configurationHost configuration
One PodUnchangedstatic IPAMNone
Multiple PodsUnchangedhost-local with one subnet per nodeNone
Same-node trafficUnchangedUnchangedLinux bridge created by plugin
Cross-node trafficUnchangedUnchangedRemote Pod-subnet routes

This separation is important. The CNI executable implements the mechanism; configuration supplies addresses and routes; the hosts provide reachability between node-local networks.

Inspect the Lifecycle

Deleting a Pod invokes DEL. The Pod-side veth disappears, which also removes its peer, and host-local releases the allocation:

1
2
3
4

POD_B_IP=$(kubectl get pod pod-b -o jsonpath='{.status.podIP}')
kubectl delete pod pod-b --wait=true
docker exec cni-lab-worker test ! -e "/var/lib/cni/networks/cni-plugin/$POD_B_IP"
echo "IP allocation released"

For CNI failures, inspect kubelet and containerd on the node that owns the Pod:

1

docker exec cni-lab-worker journalctl -u kubelet -u containerd --since '10 minutes ago' --no-pager

Useful host checks are:

1
2
3
4

docker exec cni-lab-worker ip -details link show type bridge
docker exec cni-lab-worker bridge link
docker exec cni-lab-worker ip -4 route
docker exec cni-lab-worker sysctl net.ipv4.ip_forward

What This Plugin Does Not Implement

Basic connectivity is only part of a production CNI. This implementation deliberately omits:

  • automated Pod CIDR discovery and route distribution;
  • NetworkPolicy enforcement;
  • IPv6 and dual stack;
  • IP masquerading for destinations that cannot route Pod CIDRs;
  • MTU discovery for overlays;
  • GC for leaked resources after catastrophic runtime failure;
  • metrics, health endpoints, upgrades, and reconciliation;
  • Windows networking.

It also leaves the shared bridge in place after the last Pod is deleted. That is intentional: DEL must not destroy a resource that other attachments may still use.

Clean Up

1
2

kind delete cluster --name cni-lab
rm -rf "$HOME/cni-plugin-lab"

Conclusion

A CNI plugin is easier to understand when reduced to its contract:

  1. create a connection to the Pod network namespace;
  2. obtain and apply an address;
  3. return an accurate CNI result;
  4. remove resources safely;
  5. make every Pod subnet reachable from every node.

We built the first four in one executable and made the fifth visible as ordinary Linux routes. Production CNIs automate and harden these same fundamentals at cluster scale.

References

kubernetes, networking
kubernetes networking cni golang linux
This post is licensed under CC BY 4.0 by the author.
