Kubernetes Networking Series Part 2: CNI & Pod Networking

Posted Sep 7, 2025 Updated Jan 8, 2026

Kubernetes CNI

By Simone Rodigari 22 min read

Introduction

In Part 1, we established the Model: the “Golden Rules” of Kubernetes networking. Before exploring how connections are made, let’s briefly revisit these fundamental design principles. Kubernetes departs from traditional host networking (where ports are mapped to the host IP) to simplify application migration and service discovery.

Every Pod gets its own IP: Unlike Docker’s default model where containers share the host IP and use dynamic ports, Kubernetes treats Pods like distinct VMs on the network. This means applications can run on well-known ports (like 80 or 443) without conflict, regardless of which node they land on.
Pod-to-Pod communication without NAT: The network must be flat. A Pod on Node A can reach a Pod on Node B directly using its IP address. The IP address the sender sees and uses is the exact same IP address the receiver sees as its own. The model assumes Pod IPs are directly reachable (no NAT for pod-to-pod traffic).
No Host Networking Dependence: By decoupling the application network from the underlying host network, Kubernetes creates a consistent environment. Developers don’t need to worry about the specific network configuration of the physical servers or cloud instances running their code.

But how does this actually happen? When you schedule a Pod, who creates the network interface? Who decides which IP address it gets?

This is Part 2 of our series, where we dive into the Container Network Interface (CNI). This is the mechanism that implements Part 1’s “no NAT, unique Pod IPs” rule. Instead of getting lost in the weeds of specific tools like Calico or Cilium, we will focus on the universal patterns that apply to every Kubernetes cluster.

Terminology

Before we dive in, let’s clarify a few terms used throughout this post:

Packet: A unit of data that travels over a network. Think of it as a letter in an envelope.

  graph LR
     classDef payload fill:#e91e63,stroke:#880e4f,stroke-width:2px,color:#fff
     classDef header fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff

     subgraph Packet ["Network Packet"]
       direction LR
       IP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::header ~~~ Data[Payload]:::payload
     end

Routable IP: An IP that is reachable within the cluster without NAT (i.e., other Pods/nodes can route to it directly).
IPAM (IP Address Management): The system responsible for tracking which IPs are available and assigning them to Pods. It ensures no two Pods get the same IP.
Network Namespace: A Linux kernel feature that isolates network resources (interfaces, routing tables). Each Pod gets its own namespace.
veth pair (Virtual Ethernet): A virtual cable with two ends. What goes in one end comes out the other. We use this to connect a Pod’s isolated namespace to the Node’s network.
Bridge: A virtual network switch that connects multiple network interfaces together.
Routing: The process of selecting a path for traffic in a network. In Kubernetes, this ensures packets from a Pod on one Node know how to reach a Pod on another Node.
Gateway: The next-hop IP the Pod uses as its default route (typically the node-side of the veth / bridge interface). All traffic leaving the Pod goes here first to be routed to its destination.

CNI and the OSI Model

To truly understand CNI, it helps to map its responsibilities to the OSI Model. While applications (Layer 7) and transport protocols like TCP (Layer 4) are what we interact with, CNI lives a bit lower down the stack.

The CNI plugin is primarily concerned with Layer 2 (Data Link) and Layer 3 (Network) for connectivity, and may also inspect Layer 4 when enforcing NetworkPolicies.

Layer 2 (Data Link): This is the plumbing. It involves creating the virtual ethernet cables (veth pairs), attaching them to bridges, and handling ARP/MAC addresses so that ethernet frames can move.
Layer 3 (Network): This is the addressing and routing. It involves assigning IP addresses to Pods (IPAM) and setting up the routes so that packets know where to go.

Here is a visualization of how CNI maps to the OSI layers:

graph TD
    subgraph OSI ["OSI Model Layers"]
        L7[Layer 7: Application<br>HTTP, DNS]:::grey
        L4[Layer 4: Transport<br>TCP, UDP]:::grey
        L3[Layer 3: Network<br>IP Addressing, Routing]:::blue
        L2[Layer 2: Data Link<br>Ethernet, MAC, Switching]:::green
        L1[Layer 1: Physical<br>Cables, Signals]:::grey
    end

    subgraph CNI ["CNI Responsibilities"]
        CNI3[IPAM: Assigning IPs,<br>Configuring Routes]:::blue
        CNI2[Plumbing: Creating veth pairs,<br>Attaching to Bridges]:::green
    end

    L3 --- CNI3
    L2 --- CNI2

    classDef blue fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff
    classDef green fill:#4caf50,stroke:#1b5e20,stroke-width:2px,color:#fff
    classDef grey fill:#eeeeee,stroke:#bdbdbd,stroke-width:1px,color:#757575

The Network Packet

When we talk about layers, we are really talking about how data is packaged. A network packet is like a Russian nesting doll.

graph LR
    subgraph Frame ["Ethernet Frame (Layer 2)"]
        direction LR
        L2H[Ethernet Header<br>Src/Dst MAC]:::green
        subgraph Packet ["IP Packet (Layer 3)"]
            direction LR
            L3H[IP Header<br>Src/Dst IP]:::blue
            subgraph Segment ["TCP/UDP Segment (Layer 4)"]
                direction LR
                L4H[Transport Header<br>Src/Dst Port]:::grey
                Data[Payload]:::grey
            end
        end
    end

    %% Force horizontal alignment
    L2H ~~~ L3H ~~~ L4H ~~~ Data

    classDef green fill:#4caf50,stroke:#1b5e20,stroke-width:2px,color:#fff
    classDef blue fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff
    classDef grey fill:#9e9e9e,stroke:#616161,stroke-width:2px,color:#fff

CNI Focus: The Outer Layers

In the context of CNI, we care most about the Ethernet Header and the IP Header.

Ethernet Header (Layer 2): Contains MAC addresses. Used for local delivery across the veth pair and between interfaces on the node (and out to the underlay via the node’s NIC).
IP Header (Layer 3): Contains IP addresses. This is the “global” address. The CNI ensures that a packet with a destination IP of a remote Pod gets routed to the correct Node.
Transport Header (Layer 4): Contains Ports (e.g., 80, 443). CNI plugins typically ignore this for basic connectivity. However, if you use NetworkPolicies, the CNI plugin acting as the enforcer will inspect this header to allow or deny traffic.

1. The CNI Contract (The Golden Rules)

Kubernetes itself does not handle networking. It offloads that responsibility to a CNI Plugin. It is important to note that CNI runs independently on every node, configuring local networking according to cluster-wide expectations. However, Kubernetes has strict expectations about what that plugin must provide.

Every CNI plugin must satisfy these non-negotiable requirements:

Give the Pod a unique IP: Every Pod must have an IP address that is unique within the cluster.
Make that IP reachable: Other Pods must be able to reach this IP without NAT.
Configure routes: Traffic must be able to leave the Pod and reach the rest of the network.
Clean up: When the Pod is deleted, the IP and network resources must be freed.

Key Takeaway: How this is done is up to the CNI (using bridges, routing, eBPF, etc.), but these outcomes must always be true.

Codebase References:
CNI: containernetworking/cni - The Go library and specification for writing network plugins.
CRI: kubernetes/cri-api - The definitions for the Container Runtime Interface, which triggers the CNI.

2. The Universal Pod Networking Pattern

Regardless of which CNI you use, the way a Pod connects to its Node is almost always the same. This is the most important concept to grasp.

Pod Network Namespace: The Pod runs in its own isolated network namespace.
eth0: Inside that namespace, the Pod sees a standard interface named eth0.
veth pair: This eth0 is actually one end of a Virtual Ethernet (veth) pair.
Node Connection: The other end of the pair lives in the Node’s host network namespace.

Nearly every CNI uses this pattern. The differences only start after the packet leaves the node side of the veth pair.

graph TB
    subgraph Node ["Worker Node"]

        subgraph HostNS ["Host Network Namespace"]
            NodeEth["Gateway (example)<br>10.244.1.1"]
            CNI_Mechanism["CNI Integration<br>(Bridge, Routing, eBPF)"]
            Veth_Host["veth7382"]
        end

        subgraph PodNS ["Pod Network Namespace"]
            Eth0_Pod["eth0 (10.244.1.5)"]
        end

        %% Wiring
        NodeEth --- CNI_Mechanism
        CNI_Mechanism --- Veth_Host
        Veth_Host -- "Virtual Cable" --- Eth0_Pod
    end

    style Node fill:#f9f9f9,stroke:#333,stroke-width:2px,color:#333
    style HostNS fill:#fff,stroke:#666,stroke-width:2px,color:#333,stroke-dasharray: 5 5
    style PodNS fill:#fff,stroke:#666,stroke-width:2px,color:#333,stroke-dasharray: 5 5

    classDef component fill:#333,stroke:#333,stroke-width:2px,color:#fff
    class NodeEth,CNI_Mechanism,Veth_Host,Eth0_Pod component

See it in action

You can verify this plumbing yourself on any Kubernetes node using standard Linux tools.

1. List interfaces on the host: You will see the veth interfaces, often attached to a bridge (like cni0) or just present in the list.


# On the Kubernetes Node
$ ip link show
...
3: cni0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1450 ...
4: veth7382@if3: <BROADCAST,MULTICAST,UP,LOWER_UP> ... master cni0
5: veth9123@if3: <BROADCAST,MULTICAST,UP,LOWER_UP> ... master cni0

2. Find the other end: If you exec into a Pod, you see the other end of the pipe, always named eth0.


$ kubectl exec -it my-pod -- ip link show
1: lo: <LOOPBACK,UP,LOWER_UP> ...
3: eth0@if4: <BROADCAST,MULTICAST,UP,LOWER_UP> ...

3. What Happens When a Pod Is Created (CNI Lifecycle)

Let’s walk through the generic lifecycle of a Pod’s network setup. This happens every time a Pod is scheduled.

%%{init: {'sequence': {'mirrorActors': false}}}%%
sequenceDiagram
    participant S as Scheduler
    participant K as Kubelet
    participant CR as Container Runtime
    participant C as CNI Plugin
    participant P as Pod Network

    S->>K: 1. Schedule (via API Server)
    K->>CR: 2. Create Pod Sandbox
    CR->>P: 3. Create Network Namespace
    CR->>C: 4. Call CNI ADD
    activate C
    C->>P: 5a. Create veth pair
    C->>P: 5b. Assign IP Address
    C->>P: 5c. Setup Routes
    C-->>CR: 6. Return Success
    deactivate C
    CR-->>K: 7. Sandbox Ready
    K->>CR: 8. Start App Container

Pod Scheduled: The scheduler assigns a Pod to a Node.
Kubelet Calls CRI: The Kubelet instructs the Container Runtime Interface (CRI) to create the Pod sandbox.
CRI Invokes CNI: The Container Runtime creates the network namespace and then calls the configured CNI plugin to set up the network.

CNI Actions: The plugin executes and performs the following:

Creates the veth pair.
Moves one end into the Pod’s namespace and names it eth0.
Assigns an IP to that interface (usually via an IPAM sub-plugin).

Sets up the default route inside the Pod so traffic knows where to go.


$ kubectl exec -it my-pod -- ip route show
# "default via" means: send everything else to the gateway (10.244.1.1)
default via 10.244.1.1 dev eth0
10.244.1.0/24 dev eth0 proto kernel scope link src 10.244.1.5

Connects the node-side veth to the cluster network (via a bridge, routing table, etc.).

Ready: The CNI returns success to the CRI, which reports back to the Kubelet, and the application container starts.

Verifying the Lifecycle

You can observe these steps happening (or failing) using kubectl.

1. Check Scheduling & IP Assignment: Watch the Pod status. It transitions from Pending (Scheduling) to ContainerCreating (CNI is running). Once the IP is assigned, it moves to Running.


$ kubectl get pods -o wide -w
NAME    READY   STATUS              IP           NODE
web-1   0/1     ContainerCreating   <none>       node-1  # CNI is working...
web-1   1/1     Running             10.244.1.5   node-1  # CNI finished!

2. Debugging CNI Failures: If the Pod stays in ContainerCreating, the CNI might be failing. Check the events:


$ kubectl describe pod web-1
...
Events:
  Type     Reason                  Age   From               Message
  ----     ------                  ----  ----               -------
  Normal   Scheduled               5s    default-scheduler  Successfully assigned default/web-1 to node-1
  Warning  FailedCreatePodSandBox  1s    kubelet            NetworkPlugin cni failed to set up pod "web-1_default" network: failed to find plugin "bridge" in path [/opt/cni/bin]

4. Where CNIs Differ

If the Pod-to-Node connection (the veth pair) is standard, where do the differences lie? They mostly concern how packets move between nodes and how the cluster enforces rules.

4.1. The Data Plane: Architectures

This determines how a packet from a Pod on Node A reaches a Pod on Node B.

4.1.1. Overlay Networks (Encapsulation)

What: The CNI wraps the original Pod packet inside a Node packet (Encapsulation). It creates a “tunnel” over the physical network.
Why: It works everywhere. The physical network (AWS VPC, Azure VNet, Google VPC, or your home router) only sees Node IPs. It doesn’t need to know that Pod IPs exist.
Trade-off: Slight CPU overhead for wrapping/unwrapping packets and reduced MTU (to make room for the extra headers).

High-Level View:

To understand encapsulation, let’s start with a high-level view. Imagine Pod A (10.244.1.5) on Node A (192.168.1.10) wants to send a packet to Pod B (10.244.2.5) on Node B (192.168.1.20).

The physical network only knows about Node IPs (192.168.x.x). It doesn’t know how to route Pod IPs (10.244.x.x). So, Node A wraps the packet in a “Node envelope” to get it across.

graph LR
    subgraph NodeA [Node A - 192.168.1.10]
        PodA[Pod A - 10.244.1.5]
    end

    subgraph NodeB [Node B - 192.168.1.20]
        PodB[Pod B - 10.244.2.5]
    end

    Network((Physical Network))

    PodA -- "1. Send (Encap)<br>Src: 192.168.1.10<br>Dst: 192.168.1.20" --> Network
    Network -- "2. Receive (Encap)<br>Src: 192.168.1.10<br>Dst: 192.168.1.20" --> PodB

    style NodeA fill:#f9f9f9,stroke:#333,stroke-width:2px,color:#333
    style NodeB fill:#f9f9f9,stroke:#333,stroke-width:2px,color:#333
    style PodA fill:#333,stroke:#333,stroke-width:2px,color:#fff
    style PodB fill:#333,stroke:#333,stroke-width:2px,color:#fff
    style Network fill:#fff,stroke:#333,stroke-width:2px,color:#333

Now, let’s look at the specific technologies used to achieve this.

VXLAN (Virtual Extensible LAN)

The most common encapsulation protocol.

1. Encapsulation (Sending at Node A)

When Pod A sends traffic to Pod B, the CNI and the Node’s kernel work together to wrap the packet for transport across the physical network.

Original Packet: Pod A creates a standard packet addressed to Pod B.
Overlay Header: The kernel encapsulates the frame with a VXLAN header (orange).
Physical Transport: Node A adds the UDP transport (grey) and its own Outer IP header (blue) to send it to Node B.

graph TD
    %% Dark Mode Friendly Palette
    classDef payload fill:#e91e63,stroke:#880e4f,stroke-width:2px,color:#fff
    classDef blue fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff
    classDef overlay fill:#ff9800,stroke:#e65100,stroke-width:2px,color:#fff
    classDef grey fill:#9e9e9e,stroke:#616161,stroke-width:2px,color:#fff
    classDef green fill:#4caf50,stroke:#1b5e20,stroke-width:2px,color:#fff

    subgraph Step1 ["1. Original Pod Packet"]
        direction LR
        subgraph S1_Frame [Ethernet Frame]
            direction LR
            S1_Eth[Ethernet]:::green
            subgraph S1_Packet [IP Packet]
                direction LR
                S1_IP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue
                S1_Data[Payload]:::payload
            end
        end
    end

    Step1 -->|Encapsulate Overlay| Step2

    subgraph Step2 ["2. Add VXLAN Header"]
        direction LR
        subgraph S2_VXLAN [VXLAN Overlay]
            direction LR
            S2_VNI[VXLAN VNI:100]:::overlay
            subgraph S2_Frame [Inner Frame]
                direction LR
                S2_Eth[Ethernet]:::green
                subgraph S2_Packet [Inner IP Packet]
                    direction LR
                    S2_IP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue
                    S2_Data[Payload]:::payload
                end
            end
        end
    end

    Step2 -->|Transport Outer Headers| Step3

    subgraph Step3 ["3. Final Packet on Wire"]
        direction LR
        subgraph S3_OFrame [Outer Frame]
            direction LR
            S3_OEth[Ethernet]:::green
            subgraph S3_OPacket [Outer IP Packet]
                direction LR
                S3_OIP["IP Header<br>Src: 192.168.1.10<br>Dst: 192.168.1.20"]:::blue
                subgraph S3_OUDP [UDP Segment]
                    direction LR
                    S3_UDP[UDP]:::grey
                    subgraph S3_OVXLAN [VXLAN Overlay]
                        direction LR
                        S3_VNI[VXLAN]:::overlay
                        subgraph S3_IFrame [Inner Frame]
                            direction LR
                            S3_IEth[Ethernet]:::green
                            subgraph S3_IPacket [Inner Packet]
                                direction LR
                                S3_IIP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue
                                S3_Data[Payload]:::payload
                            end
                        end
                    end
                end
            end
        end
    end

    %% Force Horizontal Alignment
    S1_Eth ~~~ S1_IP ~~~ S1_Data
    S2_VNI ~~~ S2_Eth ~~~ S2_IP ~~~ S2_Data
    S3_OEth ~~~ S3_OIP ~~~ S3_UDP ~~~ S3_VNI ~~~ S3_IEth ~~~ S3_IIP ~~~ S3_Data

2. Decapsulation (Receiving at Node B)

At the destination, the envelope is peeled open layer by layer.

Receive on Wire: Node B (192.168.1.20) receives the full packet.
Strip Transport: The Kernel sees the packet is for itself, removes the Outer IP header (blue) and UDP (grey).
Unwrap: The VXLAN interface removes the VXLAN header (orange).
Deliver: The original packet (Src: Pod A, Dst: Pod B) is revealed and delivered.

graph TD
    %% Dark Mode Friendly Palette
    classDef payload fill:#e91e63,stroke:#880e4f,stroke-width:2px,color:#fff
    classDef blue fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff
    classDef overlay fill:#ff9800,stroke:#e65100,stroke-width:2px,color:#fff
    classDef grey fill:#9e9e9e,stroke:#616161,stroke-width:2px,color:#fff
    classDef green fill:#4caf50,stroke:#1b5e20,stroke-width:2px,color:#fff

    subgraph Rx_Step1 ["1. Receive on Wire"]
        direction LR
        subgraph R1_OFrame [Outer Frame]
            direction LR
            R1_OEth[Ethernet]:::green
            subgraph R1_OPacket [Outer IP Packet]
                direction LR
                R1_OIP["IP Header<br>Src: 192.168.1.10<br>Dst: 192.168.1.20"]:::blue
                subgraph R1_OUDP [UDP Segment]
                    direction LR
                    R1_UDP[UDP]:::grey
                    subgraph R1_OVXLAN [VXLAN Overlay]
                        direction LR
                        R1_VNI[VXLAN]:::overlay
                        subgraph R1_IFrame [Inner Frame]
                            direction LR
                            R1_IEth[Ethernet]:::green
                            subgraph R1_IPacket [Inner Packet]
                                direction LR
                                R1_IIP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue
                                R1_Data[Payload]:::payload
                            end
                        end
                    end
                end
            end
        end
    end

    Rx_Step1 -->|Strip Outer Headers| Rx_Step2

    subgraph Rx_Step2 ["2. Allow through Overlay"]
        direction LR
        subgraph R2_VXLAN [VXLAN Overlay]
            direction LR
            R2_VNI[VXLAN VNI:100]:::overlay
            subgraph R2_Frame [Inner Frame]
                direction LR
                R2_Eth[Ethernet]:::green
                subgraph R2_Packet [Inner IP Packet]
                    direction LR
                    R2_IP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue
                    R2_Data[Payload]:::payload
                end
            end
        end
    end

    Rx_Step2 -->|Decapsulate| Rx_Step3

    subgraph Rx_Step3 ["3. Deliver to Pod"]
        direction LR
        subgraph R3_Frame [Inner Frame]
            direction LR
            R3_Eth[Ethernet]:::green
            subgraph R3_Packet [Inner IP Packet]
                direction LR
                R3_IP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue
                R3_Data[Payload]:::payload
            end
        end
    end

    %% Force Horizontal Alignment
    R1_OEth ~~~ R1_OIP ~~~ R1_UDP ~~~ R1_VNI ~~~ R1_IEth ~~~ R1_IIP ~~~ R1_Data
    R2_VNI ~~~ R2_Eth ~~~ R2_IP ~~~ R2_Data
    R3_Eth ~~~ R3_IP ~~~ R3_Data

Geneve (Generic Network Virtualization Encapsulation)

While VXLAN is the most common example, you often see Geneve used in modern CNIs.

VXLAN has a fixed header format with limited space for metadata (just the VNI ID).
Geneve is designed to be extensible. It supports variable-length options (Type-Length-Value or TLV) inside the header.

Advanced CNIs like Cilium or OVN-Kubernetes use Geneve to embed rich context directly into the packet, such as policy/security metadata, to carry additional metadata alongside the packet.

IPIP (IP-in-IP)

IPIP is a simpler protocol that encapsulates one IP packet inside another.

Pros: Lower overhead than VXLAN (adds fewer bytes) because it doesn’t need an Ethernet or UDP header.
Cons: Carries only IP traffic (no Layer 2 / Ethernet support).

4.1.2. Direct Routing (No Encapsulation)

What: Pod packets are sent “naked” (without encapsulation) onto the physical network. The physical network routers are taught how to route Pod IPs directly to the correct Node.
Why: Best performance (no MTU overhead, no CPU cost for encap/decap) and easier troubleshooting (standard tools like tcpdump work everywhere).
Trade-off: Requires configuration of the physical network (BGP Peering) or a flat Layer 2 network.

BGP (Border Gateway Protocol)

How does it work?

In this model, the CNI plugin runs a routing daemon (like BIRD, commonly used by Calico, or another BGP daemon) on every node. This daemon talks to the physical routers (Top-of-Rack) and announces: “Hey, I have the subnet 10.244.1.0/24. Send all packets for those IPs to me (Node A).”

Because the physical network knows where every Pod IP lives, packets flow natively without any modification.

graph LR
    subgraph NodeA [Node A - 192.168.1.10]
        PodA[Pod A - 10.244.1.5]
        BGP_A[BGP Agent]
    end

    subgraph NodeB [Node B - 192.168.1.20]
        PodB[Pod B - 10.244.2.5]
        BGP_B[BGP Agent]
    end

    Router((Physical Router))

    %% Control Plane
    BGP_A -. "I have 10.244.1.x" .-> Router
    BGP_B -. "I have 10.244.2.x" .-> Router

    %% Data Plane
    PodA -- "Src: 10.244.1.5<br>Dst: 10.244.2.5" --> Router
    Router -- "Routes to Node B" --> PodB

    style NodeA fill:#f9f9f9,stroke:#333,stroke-width:2px,color:#333
    style NodeB fill:#f9f9f9,stroke:#333,stroke-width:2px,color:#333
    style PodA fill:#333,stroke:#333,stroke-width:2px,color:#fff
    style PodB fill:#333,stroke:#333,stroke-width:2px,color:#fff
    style BGP_A fill:#fff,stroke:#333,stroke-width:1px,color:#333,stroke-dasharray: 5 5
    style BGP_B fill:#fff,stroke:#333,stroke-width:1px,color:#333,stroke-dasharray: 5 5
    style Router fill:#fff,stroke:#333,stroke-width:2px,color:#333

    linkStyle 0 stroke:#666,stroke-width:2px,stroke-dasharray: 5 5
    linkStyle 1 stroke:#666,stroke-width:2px,stroke-dasharray: 5 5

Unlike encapsulation, the packet on the wire looks exactly like the packet that left the Pod. There is no “Outer Header”.

graph LR
    %% Dark Mode Friendly Palette
    classDef payload fill:#e91e63,stroke:#880e4f,stroke-width:2px,color:#fff
    classDef blue fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff
    classDef green fill:#4caf50,stroke:#1b5e20,stroke-width:2px,color:#fff

    subgraph Wire ["Packet on the Wire (No Encapsulation)"]
        direction LR
        Eth[Ethernet]:::green ~~~ IP["IP Header<br>Src: 10.244.1.5<br>Dst: 10.244.2.5"]:::blue ~~~ Data[Payload]:::payload
    end

Host-Gateway

A simplified form of direct routing for small clusters.

Mechanism: Instead of using BGP to talk to routers, nodes update each other’s routing tables.
Requirement: All nodes must be on the same Layer 2 subnet (connected to the same switch/VLAN).
Limitation: It cannot route across different subnets.

4.1.3. Which dataplane am I using?

There are three main ways to check: inspecting the node, asking the CNI, or catching it in the act.

1. Inspect the Node (Universal) Check the network interfaces and routing table.


# 1. Look for tunnel interfaces (one common case)
$ ip -d link show | grep vxlan
# Output: vxlan.calico ... (Presence usually implies Overlay)

# 2. Check how the Node reaches a Pod subnet (e.g., 10.244.1.0/24)
$ ip route get 10.244.1.5
# Overlay: "dev vxlan.calico" (It goes into a tunnel interface)
# Direct:  "via 192.168.1.10 dev eth0" (It goes directly to the other Node's IP)

2. Ask the CNI (Best Practice) Modern CNIs have CLI tools that tell you exactly how they are configured.

Cilium: The CLI on your laptop just shows cluster health. To see the network mode, run the status command inside a Cilium Pod:


  $ kubectl -n kube-system exec -ti ds/cilium -- cilium status | grep -i "Tunnel"
  # Example outputs (varies by version):
  # "Routing: Network: Tunnel [vxlan] ..." (Overlay)
  # "Routing: Network: Native ..." (Direct Routing)

Calico: Check the Installation resource (if using the Operator) and IPPool.
- kubectl get installation default -o yaml -> Look for calicoNetwork.linuxDataplane (values: Iptables or BPF).
- kubectl get ippool -o yaml -> Check vxlanMode (values: Never, Always, CrossSubnet).

3. The “Ground Truth” (tcpdump) If you are still unsure, sniff the traffic on the physical interface (eth0) while pinging between Pods.


# Capture packets on the physical node interface (VXLAN uses port 4789)
$ tcpdump -i eth0 -n port 4789
# If you see packets matching your ping timing, you are using VXLAN (Overlay).
# If you capture nothing but the ping still works, you are likely using Direct Routing.

4.2. The Enforcement Mechanism: iptables vs. eBPF

This determines how a node implements Service virtual IP translation/load balancing and NetworkPolicy enforcement (iptables/IPVS vs eBPF, depending on the cluster). Before the packet even reaches the Pod, it must pass through this logic.

Services (NAT & Load Balancing): The packet is destined for a virtual ClusterIP. The kernel must intercept it and perform DNAT (Destination NAT) to translate the destination IP to a specific real Pod IP. (We will cover these mechanics in detail in Part 3).
Firewall (Network Policy): The kernel checks if the source is allowed to talk to that destination.

graph LR
    %% Dark Mode Friendly Palette
    classDef packet fill:#e91e63,stroke:#880e4f,stroke-width:2px,color:#fff
    classDef blue fill:#2196f3,stroke:#0d47a1,stroke-width:2px,color:#fff
    classDef green fill:#4caf50,stroke:#1b5e20,stroke-width:2px,color:#fff
    classDef pod fill:#333,stroke:#333,stroke-width:2px,color:#fff

    Incoming[Incoming Packet]:::packet --> NodeLogic

    subgraph NodeLogic ["Enforcement Logic"]
        direction TB
        Service["1. Service (DNAT & LB)<br>ClusterIP &rarr; Pod IP"]:::blue
        Policy["2. Policy (Firewall)<br>Is this traffic allowed?"]:::green

        Service --> Policy
    end

    Policy -->|Yes| Pod[Target Pod]:::pod
    Policy -->|No| Drop(X):::pod

iptables (Legacy Standard)

What: Uses the Linux kernel’s built-in firewall lists. kube-proxy updates thousands of rules to redirect traffic.
Why: It is the default, stable, and works on every Linux kernel.
Trade-off: Gets slow at scale. If you have 10,000 Services, the kernel has to check a massive list of rules for every packet.

graph LR
    subgraph IPT [iptables Linear Lookup]
        direction LR
        P1[Packet] --> R1(Rule 1)
        R1 -- No --> R2(Rule 2)
        R2 -- No --> R3(...)
        R3 -- No --> RN(Rule N)
        RN -- Yes --> Dest1[Destination]
    end

eBPF (Modern Approach)

What: The CNI loads custom, programmable logic directly into the kernel. It uses efficient hash maps to look up destinations instantly.
Why: Blazing fast at any scale and provides deep observability.
Trade-off: Requires newer Linux kernels.

graph LR
    subgraph EBPF [eBPF Hash Lookup]
        direction LR
        P2[Packet] --> Map(eBPF Map)
        Map -- "O(1)" --> Dest2[Destination]
    end

Which Service implementation am I using?

Check if kube-proxy is running or if your CNI has replaced it.


# Check if kube-proxy is running
$ kubectl get pods -n kube-system -l k8s-app=kube-proxy
# If you see pods: You are likely using iptables (or IPVS).
# If empty: Your CNI (like Cilium) may have replaced it with eBPF.

# If using Cilium, ask it directly:
$ cilium status | grep KubeProxyReplacement
# KubeProxyReplacement: Strict (eBPF is handling everything)

5. Why This Abstraction Matters

Understanding this universal pattern is crucial for the rest of our journey:

Services (Part 3): Services assume that Pods already have routable IPs. They build load balancing on top of this foundation.
DNS (Part 4): DNS relies on Services resolving to these reachable Pod IPs.
Debugging (Part 5): Troubleshooting always starts at the Pod interface (eth0) and works outward. If the veth pair isn’t working, nothing else matters.

Summary

We have demystified the plumbing. We know that a CNI plugin is responsible for satisfying the “Golden Rules” and that it uses a standard veth pair pattern to connect Pods to the Node.

“Once you understand how a Pod connects to its node, everything else in Kubernetes networking becomes easier, regardless of which CNI your cluster uses.”

What’s Next

At this point, Pods have IPs and can reach each other, but users don’t talk to Pods directly.

In Part 3, we’ll tackle the next big challenge: Services. Now that we have a flat network where Pods can communicate freely, we face a new problem: Pod IPs are ephemeral and change when Pods are rescheduled or restarted. How do we reliably route traffic to a moving target?

We’ll explore how Services and kube-proxy build on top of the CNI foundation to provide stable virtual IPs, service discovery, and load balancing.

References

Kubernetes CNI: Network Plugins
CNI Specification: Container Network Interface (CNI)
Cilium: GitHub
Calico: GitHub
eBPF: Documentation
iptables: netfilter.org
VXLAN: RFC 7348
IPIP: RFC 2003
BGP: RFC 4271

kubernetes, networking

This post is licensed under CC BY 4.0 by the author.
